IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
50
>
13.2 PROFINET
Content
Parameter data .......................................................................................................................................50
Cyclic data ..............................................................................................................................................53
Acyclic data ............................................................................................................................................55
33674
>
13.2.1 Parameter data
34546
Slot
Subslot
Name
Description
1
1
Master
Parameter data of the IO-Link master (→ Parameter of the IO-Link master (→ S. 50))
2
Port X01
 Parameter data of the IO-Link ports (→ Parameters of the IO-Link ports (→ S. 51)
 modules (→ PROFINET modules (→ S. 53))
3
Port X02
4
Port X03
5
Port X04
6
Port X05
7
Port X06
8
Port X07
9
Port X08
>
Parameter of the IO-Link master
34552
Parameter
Description
Possible values
[Access Rights]
The access rights to the
parameter data, process data and
events/diagnostic messages of
the IO-Link master and the
connected IO-Link devices
PROFINET + IoT
 PROFINET and LR DEVICE have read
and write access rights to parameters
and process data
 PROFINET and LR DEVICE have read
access rights to events/alarms
PROFINET + IoT (ro)
 PROFINET has read and write access
rights to parameters and process data
 PROFINET has read access rights to
events/alarms
 LR DEVICE only has read access
rights to parameters, process data and
events/alarms
PROFINET only
 PROFINET has read and write access
rights to parameters and process data
 PROFINET has read access rights to
events/alarms
 LR DEVICE has no access rights
(parameters, process data,
events/alarms, web interface, firmware
update)
keep setting
keeps settings
>
