Explanations submenu OUT1
Parameter Explanation and setting options
SEL1 standard unit of measurement for evaluation by OUT1:
FLOW (volumetric flow) or TEMP (temperature) or PRES (pressure)
ou1 output function for OUT1:
• flow Hno, Hnc, Fno, Fnc, ImP, OFF
• temperature: Hno, Hnc, Fno, Fnc, OFF
• pressure: Hno, Hnc, Fno, Fnc, OFF
Hno = switching signal with hysteresis function normally open
Hnc = switching signal with hysteresis function normally closed
Fno = switching signal with window function normally open
Fnc = switching signal with window function normally closed
ImP = consumed quantity monitoring (totaliser function)
OFF = output OFF (of high impedance)
SP1 set point for OUT1
rP1 reset point for OUT1
FH1 upper limit value for OUT1
FL1 lower limit for OUT1
ImPS1 pulse value = volumetric flow quantity at which 1 pulse is delivered�
ImPR1 configuration of OUT1 for consumed quantity monitoring:
YES (pulse signal), no (switching signal)�
dS1 switching delay on OUT1
dr1 switch-off delay on OUT1
FOU1 response of OUT1 / OUT2 in case of an internal fault:
OU = output switches irrespective of the error as defined with the
parameters�
On = output switches ON / analogue signal goes to 21�5 mA�
OFF = output switches OFF / analogue signal goes to 3�5 mA�
FOU1 is not available if ou1 = ImP was selected�
