29
UK
Explanation submenu CFG
Parameter Explanation and setting options
uni�F standard unit of measurement for volumetric flow
uni�T standard unit of measurement for temperature
uni�P standard unit of measurement for pressure
dAP�F measured value damping for volumetric flow
dAP�P measured value damping for pressure
P-n output logic
diA Indication of the internal pipe diameter in mm
LFC low flow cut-off
rEF�P standard pressure to which the measured and display values for volumet-
ric flow refer
rEF�T standard temperature to which the measured and display values for
volumetric flow refer
coF Zero-point calibration for pressure measurement� The internal measured
value "0" is shifted by this value�
