12
Step 1
2.6 Install Direction
Signboard arcylic
Light box pirate
decorations
Ad(advertisement) nail
Light-box assembly
Light box
plactic screw
upper maintenance
door
Game-machine
assembly
Take out the light box assembly, decorate the light box pirate with 3 advertisement
snails fixed in the light box assembly, then take out the advertisement nail
assembly from the attached product box, install in the light box to assemble the
remaining 4 advertisement nails, and finally use the advertisement snail wire to
hold the machine type of pressure fixed.
Step 2
Take out the game-machine assembly, open the upper access door, use the
rubber-head screws to fix the light box, connect the connector properly, and then
reinstall it
Special attention:When special case occurs in shipment, please check “Installation guide” in attachment box
of shipment, and make assembly according to installation guide; special supplement will
not be made in this instruction.
