IGS Pirate Falls - Left Loudspeaker Mesh Assembly

52
6.2.1.7 Glass-frame assembly(PT-0108000)
1
1
3
6
2
1
4
4 Hex head Cap Screw M4（Colour） 18 1.6.LM204013
3 PT-0108A02 Glass plate SECC-1.5T 6 1.1.IG31A00100
2 WAH-0000C07 47-inch LED glass A Glass-5.0T 1 1.8.AA030070
1 PT-0108A01 Glass frame SPCC-1.2T 1 1.1.IG31A00090
No. Draw No. Name Material/Spec. Qty. Product Code
