IGS Pirate Falls - Host Assembly

48
6.2.1.4 LCD assembly(PT-0104000)
1
1
3
1
2
1
4
3
4
3
4
cross recessed fillister head
three-combination screw
M6*16（chrome） 6 1.6.LS861032
3 PT-0104A02 LCD bracket B 1 1.1.IG31A00060
2 PT-0104A01 LCD bracket A 1 1.1.IG31A00050
1 LED(47 inch led with frame) 1 1.4.XS404740
No. Draw No. Name Material/Spec. Qty. Product Code
