IGS Pirate Falls - Assembly; Assembly Tree Diagram

39
PT-0000000-
General assembly drawing
PT-0100000
Frame assembly
PT-0101000 Wooden frame assembly
PT-0103000 Right wooden-frame assembly
PT-0104000 LCD assembly
PT-0105000 AC power-box assembly
PT-0106000 Transformer assembly
PT-0107000 Host assembly
PT-0108000 Glass-frame assembly
PT-0109000 Right loudspeaker mesh assembly
PT-0110000 Left loudspeaker mesh assembly
PT-0111000 Decorative light-bar assembly
PT-0112000 Control-panel button assembly
PT-0201000 No.1 bearing assembly
PT-0202000 No.2 bearing assembly
PT-0203000 Sensor assembly
PT-0102000 Left wooden-frame assembly
PT-0200000
Barrel assembly
PT-0300000
Light box assembly
PT-0400000
Ticket-door assembly
PT-0500000
Control panel assembly
PT-0600000
Lower access door assembly
PT-0700000
Upper access door assembly
6.1 Assembly tree diagram
6. Assembly
