62
6.2.4 Ticket-door assembly(PT-0400000)
1
1
4
1
2
1
1
1
3
1
5
1
5
6
2
6
1
6
2
9 UYG-0400A05 Lottery door limit hardware B SECC-1.5T 1 1.1.IG26C00310
8 UYG-0400A04 Lottery door limit hardware A SECC-1.5T 1 1.1.IG26C00300
7 Cross the big flat head screw
M3*8（chrome）
5 1.6.LS230032
6 Hex head Cap Screw
M4（Colour）
5 1.6.LM204013
5 Curved skew baffle lock plate
（NO.001）
1 1.4.SJ500060
4 Lock 5555S 1 1.4.SJ120110
3 PT-0400A03 Lottery door hinge SPCC-1.2T 1 1.1.IG31A00300
2 PT-0400A02 Lottery machine frame 1 1.1.IG31A00290
l PT-0400A01 Ticket dispenser door SPCC-1.2T l 1.1.IG31A00280
No. Draw No. Name Material/Spec. Qty. Product Code
To Next Page
