IGS Pirate Falls - Replacement of Button on Control Panel; Replacement of Loudspeaker

37
1.Remove 8 screws from the control
panel and remove the control panel
button assembly;
5.2.6 Replacement of button on the control panel
1.Remove 4 screws from the loudspeaker mesh assembly to remove the loudspeaker
mesh assembly. Remove 4 screws from the loudspeaker to replace the loudspeaker;
Reinstall in a reverse order after replacement.
5.2.7 Replacement of the loudspeaker
2.Remove the button on the control panel
for replacing.Reinstall in a reverse order
after replacement.
Control-panel
button assembly
Button
Loudspeaker
mesh assembly
Loudspeaker
