IGS Pirate Falls - Pirate Treasure House Assembly

49
6.2.1.5 AC power-box assembly(PT-0105000)
1
1
2
1
3
2
4
2
4 Hex head Cap Screw M4（Colour） 2 1.6.LM204013
3 Cross the big flat head screw M3*8（Black） 2 1.6.LS230081
2 Filter with switch YB11C1-10A-Q 1 1.4.LB100090
1 PT-0105A01 AC Power Box SPCC-1.2T 1 1.1.IG31A00070
No. Draw No. Name Material/Spec. Qty. Product Code
