IGS Pirate Falls - Frame Assembly

41
20 Plactic screw
M6*35
（Galvanization）
4 1.6.LSU63024
19 Hex Socket Cap Screws M4*25（chrome） 6 1.6.LS142022
18 Hex Socket Cap Screws M4*30（Black） 8 1.6.LS143011
17 Hex head Cap Screw M4（Colour） 8 1.6.LM204013
16 Carriage Bolts M4*30（chrome） 6 1.6.LSP43012
15 Hex Socket Cap Screws M4*12（chrome） 4 1.6.LS141022
14 Hex Head Cap Screw(BS) M8*30（Black） 4 1.6.LSM83011
13 Spring washer M8（Black） 4 1.6.DP208011
12 Plain washers
φ8*φ22*2.0
（Black）
4 1.6.DP108031
11
Cross recessed fillister head
three-combination screw
M6*16（Black） 2 1.6.LS861031
10 PT-P0003 In front of the screen PMMA-5.0T 1 1.7.IG31A00140
9 PT-0700000 Upper access door assembly 1
8 PT-0600000 Lower access door assembly 1
7 TYM-0000000A Single coin door frame 1 2.1.AA030012
6 PT-0000A01 Spindle cover 1 1.1.IG31A00010
5 PT-0500000 Control panel assembly 1
4 PT-0400000 Ticket-door assembly 1
3 PT-0300000 Light box assembly 1
2 PT-0200000 Barrel assembly 1
1 PT-0100000 Frame assembly 1
No. Draw No. Name Material/Spec. Qty. Product Code
