IKONIX Associated Research Hypot III User Manual

29
Menu
Pressing the “Menu” soft key from the Main Menu will display the Results, Test and
System selections. Please refer to section 5.2.3. Results, Test, and System
Selections.
Memory
The Hypot III has 10, 3-step programmable memory locations (M0-M9). Press the
“Memory” soft key to increment the instrument to the desired memory location. As the
“Memory” soft key is pressed, the parameters of the selected memory location are
automatically loaded into the instrument.
Step
Each of the 10 memory locations in Hypot III has 3 programmable test steps that may
be connected together to create a multi-step test sequence. Press the “Step” soft key
to increment the test step number.
4.1.3. Results, Tests and System Selections
From the Main Menu, press the “Menu” soft key.
From this screen, three software controls may be accessed: Results, Test and
System. Pressing the “Exit” soft key at any time will return you to the Main Menu
screen.
Results
Pressing the “Results” soft key from this menu will allow you to review the test results
of the last test performed. An example of a Results screen is shown below.
