11. REPLACEMENT PARTS LIST
ECO: 5611 Rev.H 5-6-2013
Part
Number
Qty.
Reference
Designator
Description
38787
2
2
-
3U Rack Mount Handle
38788
2
2
-
3U Rack Mount Bracket
39714
2
4
-
Screw for Rack Mount
Handle/Bracket
35999
4
-
Black Banana Jacks
37497
1
-
Reset Switch, Red
37555
1
1
-
Power Switch 2P 10A/250V
37571
1
-
Earth Connector
39391
1
Test/Pass
Replacement Bulb
39392
1
Reset/Fail
Replacement Bulb
37673
1
-
Switch Test, Green
37783
1
RY1
Relay Gunther 3390-1290-246
37784
1
RY2
Relay Gunther 3392-1290-246
37880
1
1
-
3.15 Amp, fast acting 250VAC
38430
2
1
-
115Vac, 230VAC - 15A/250VAC
Slow-Blow
37863
1
-
RS-232 Cable
33189
1
1
-
Cable Input Cordset USA
38071
2
-
Cable Input Cordset USA 15A
38075
1
-
Interlock Connector
38101
1
-
Feet Kit w/o Rubber Inserts
38102
4
-
Rubber Insert for Feet
36544
1
-
Adapter Box
38262
3
1
IC19
Microcontroller 78E516B PLCC
39350
1
IC 19
Microcontroller 59128 PLCC
38367
1
1
CON 3670
Main Control Board
39267
2
1
CON 3670
Main Control Board
38264
1
1
HV 3670
High Voltage Board
39268
2
1
HV 3670
High Voltage Board
38265
2
1
HRY 3670
HV Relay Board
38266
1
1
AMP 3670
Power Amplifier Board
39266
2
1
AMP 3780
Power Amplifier Board
38267
1
KEY 3670
Keypad Board
38268
1
1
PWR 3670
Input Voltage Select PCB
39269
2
1
REM 3780
Remote Board
38271
1
-
High Voltage Connector w/10cm
cable
38272
1
-
High Voltage Connector w/10cm
cable
38287
1
T1
Input Transformer
