INSULATION RESISTANCE TEST MODE
Maximum Limit
Range:
0.0 , 1.0 – 999.9 M (0 = Off)
Resolution
0.1 M
Range
1000 – 9999 M
Resolution
1 M
Accuracy
Same as Resistance display
Minimum Limit
Range:
1.0 – 999.9 M
Resolution
0.1 M
Range
1000 – 9999 M
Resolution
1 M
Accuracy
Same as Resistance display
02 5 mA Output (3705, 3765, 3770 only)
The 5 mA Output option limits the output current of the instrument using software
control. The trip points are adjusted to a maximum of 5 mA and the software has
been modified so the high-speed maximum current shutdown is fixed at 5 mA. The
following specifications have been changed for this option:
DIELECTRIC WITHSTAND TEST MODE
Output Rating
5000V @ 5 mA AC
6000V @ 5 mA DC
Maximum Limit AC
Range:
0.00 - 5.00 mA
DC
Range:
0 - 5000 A
Minimum Limit AC
Range:
0.000 - 0.500 mA
DC
Range:
0.0 - 50.0 A
03 5Ω Continuity (all models)
The 5Ω Continuity option increases the Ground Continuity maximum limit from 1.5Ω to
5Ω and increases the Ground Continuity offset range from 0.0Ω – 0.50Ω to 0.0Ω –
0.99Ω. The following specifications have been changed for this option.
DIELECTRIC WITHSTAND TEST MODE
Ground Continuity
Maximum Limit
Minimum Limit
Range:
Resolution
Accuracy
0.0Ω – 5.00Ω
0.01Ω
Ω (3% of setting + 0.02Ω)
Ground Continuity
Auto Offset
Range:
Resolution
Accuracy
0.0Ω - 0.99Ω
0.01Ω
Ω (3% of setting + 0.02Ω)
Calibration
The Calibration Procedure varies slightly with this option installed. The changes to the
calibration procedure are as follows:
