57
Introduction
This section contains descriptions of available factory installed options at the time of
this printing. The list of options contains an option code number that can be
referenced on the data plate on the rear panel of the unit.
Option Label
On the rear panel of the instrument, you will find a label that contains the option code.
For example, your options code would appear as follows:
Fitted with option 01….........................................................
Fitted with option 01 and 02................................................
Hypot III Options
Option List
Description
01 0.1 MOhm Resolution (3770 only)
The 0.1 MΩ Resolution IR Limits option increases the resolution of the Max and Min
trip point limits from 1M to 0.1M, in the range of 0.0 to 999.9M.
The Max and Min Lmt set points automatically range while being edited according to
the specification table below. This is unique only to this feature because this option
has multiple ranges.
