IKONIX Associated Research Hypot III User Manual

56
Displayed
Message
Example Query Response
Memory-
Step
Test
Type
Status
Meter 1
(Voltage)
Meter 2
(Leakage
Current)
Meter 3
(Timer)
Dwell
M1-1
ACW
Dwell
0.30kV
0.296mA
0.5s
Dwell
M1-2
DCW
Dwell
1.00kV
Dwell
M1-3
IR
Dwell
0.50kV
For example, if a 3700 unit running an ACW test at 3800V and reading 2.3mA leakage
current was queried with the TD? command 1.2sec into the dwell cycle, it would
respond with:
M1-1,ACW,Dwell,3.80,2.30,1.2
The table below shows queries response examples for every displayed message type:
Displayed Message
Example Query Response
Dwell
M1-1 ,ACW,Dwell,0.30kV,0.296mA,0.5s
Delay
M1-1 ,ACW,Delay,0.30kV,0.192mA,0.2s
Ramp UP
M1-1 ,ACW,Ramp UP,0.15kV,0.090mA,0.1s
Ramp DN
M1-1 ,ACW,Ramp DN,0.10kV,0.122mA,10.0s
Pass
M1-1 ,ACW,Pass,1.00kV,0.296mA,2.0s
Abort
M1-1 ,ACW,Abort,0.30kV,0.291mA,0.4s
Max Fail
M1-1 ,ACW,Max Fail,0.30kV,0.296mA,0.2s
Min Fail
M1-1 ,ACW,Min Fail,0.30kV,0.296mA,0.2s
Cont Max
M1-1 ,ACW,Cont Max,0.30kV,0.296mA,0.2s
Cont Min
M1-1 ,ACW,Cont Min,0.30kV,0.296mA,0.2s
Arc Fail
M1-1 ,ACW,Arc Fail,1.97kV,0.613mA,1.2s
Short
M1-1 ,ACW,Short,1.23kV,0.720mA,0.5s
Breakdown
M1-1 ,ACW,Breakdown,0.30kV,0.300mA,10.0s
GND Fault
M1-1 ,ACW,GND Fault,0.40kV,0.290mA,11.0s
