7.2.3. Test Parameter Editing Commands

These commands are used to modify the test parameter within each step. These

commands require a parameter value to be included with the command. The values

for ACW and DCW tests are sent in kV while the values for an IR test are sent in V.

The writing of the parameter requires that the unit not be included with the value, only

the numeric value should be included with the command. Many of the commands will

function the same way for multiple test types; however, the input range may be

different and therefore used a different possible set of values.

Command

Name

Test Types

Value

CONN {1|0}

Connect ON/OFF

ALL

1=On, 0=Off

VOLT <value>

Set Voltage Level

ACW

DCW

0-5kV

0-6kV

0-1000V

RUP <value>

Edit Ramp Up

ALL

0.1-999.9sec

RDN <value>

Edit Ramp Down

ACW

DCW

0.1-999.9sec

0, 1.0-999.9sec

DDT <value>

Dwell/Delay Time

ACW

DCW

0, 0.3-999.9sec

0, 0.4-999.9sec

0, 0.5-999.9sec

ARC <value>

Arc Detect Level

ACW

DCW

1-9

MAXL <value>

Edit Max Limit

ACW

DCW

0.00-20.0mA

(3705,3765,3770)

0.00-99.99mA

(3780)

0-7500uA

0, 1-9999MOhms

MINL <value>

Edit Min Limit

ACW

DCW

0.000-9.999mA

0.0-999.9uA

1-9999MOhms

FREQ {50|60}

Edit Frequency

ACW

50 or 60Hz

CONT {1|0}

Continuity

ON/OFF

ACW

DCW

1=On, 0=Off

CMAL <value>

Continuity Max

Limit

ACW

DCW

0.00-1.50Ohms

CMIL <value>

Continuity Min

Limit

ACW

DCW

0.00-1.50Ohms
