52
SALL<memory+step,type,p1,p2,p3…>
Add all
Parameters of a
Test
MSS<memory number step number>
Load a file by memory and step number. The first digit is the memory number and the
second digit is the step number. Example: MSS <11> = memory 1 step 1
ACW, DCW, IR
These commands add the appropriate test type within the memory at the step location
that has been selected. The parameters of the previous test type will be deleted and
the default values for the new test type will be recalled. If the same test type is
selected that already exists, the default values will replace the previous parameters.
SALL <memory+step, type, p1, p2, p3… >
This command edits all parameters in a memory and step. Parameters will be edited
at the step location that has been selected. See the command summary tables to see
the specific test type for each of these commands. Example:
SALL<01,ACW,1.24,10.00…>
The parameter <memory+step> indicated the memory and step number. The
parameter <type> indicated the test type. The values ACW, DCW, or IR must be used.
The parameters <p1,p2> etc. indicate the individual settings for each test. All
parameters must be included with the command and should appear in the same order
that is shown in the table below. Also, like the individual parameter editing commands,
the unit should not be included with the value. Only the numeric value should be
included in the command string. The list of parameters can also be found in the
default parameters section of the manual, or refer to the Test Parameter Editing
commands section for the proper values. The parameter values should use complete
text and not use the coded values that are associated with the individual parameter
setting commands such as "ON" and "OFF" for toggle field.
