IKONIX Associated Research Hypot III User Manual

18
3.2. 3780 Functional Specifications
INPUT
Voltage
115/230 VAC  15, automatically selected
Frequency
50/60 Hz  5%
Fuse
15 Amp, slow-blow 250VAC
DIELECTRIC WITHSTAND TEST MODE
Output Rating
5000V @ 100 mA AC
Voltage Setting
Range:
0 – 5.00KV AC
Resolution:
0.01KV
Accuracy:
 (2 of setting  0.01KV)
(Adjustable during operation.
Disabled when key lockout is active.)
Maximum Limit AC
Range:
0.00 – 99.99 mA
Resolution:
0.01 mA
Minimum Limit AC
Range:
0.000 – 9.999 mA
Resolution:
0.001 mA
Accuracy:
 (2 of setting  6 counts)
Arc Detection
Range:
0 – 9, 0 disabled
Failure Detector
Audible and Visual
Ground Fault Interrupt
GFI Trip Current: 450A max
HV Shut Down Speed: <1ms
Voltage Display
Range:
0.00 – 5.00KV AC
Resolution:
0.01KV
Accuracy:
 (2 of reading  0.01KV)
