DIELECTRIC WITHSTAND TEST MODE
Current Display
Auto Range
AC
Range 1:
0.000mA – 3.500mA
Resolution:
0.001mA
Accuracy:
 (2 of setting  2 counts)
Range 2:
3.00 – 99.99 mA
Resolution:
0.01 mA
Accuracy:
 (2 of setting  6 counts)
AC Voltage Wave Form
Sine Wave, Crest Factor = 1.3 – 1.5
Output Frequency
Range:
50 or 60 Hz, User Selectable
Accuracy:
 0.1%
Output Voltage
Regulation
 (1  of output  5 volts)
from no load to full load and over input voltage range.
Dwell Timer
Range:
0, 0.3 – 999.9 sec (0 = Constant)
Resolution:
0.1 sec
Accuracy:
 (0.1% of reading + 0.05 sec)
Ramp Timer
Range:
Ramp-Up: 0.1 – 999.9 sec
Ramp-Down: AC 0.0 – 999.9 sec
Resolution:
0.1 sec
Accuracy:
 (0.1% of reading + 0.05 sec)
Ground Continuity
Current
DC 0.1 A  0.01A, fixed
Ground Continuity
Range:
0.0 - 1.50
Maximum Limit
Resolution:
0.01
Minimum Limit
Accuracy:
 (3% of setting + 0.02)
Ground Continuity
Range:
0.0 - 0.50
Auto Offset
Resolution:
0.01
Accuracy:
 (3% of setting + 0.02)
Output Short Circuit
Current
> 200mA
Why use the term “Counts”?
Associated Research publishes some specifications using COUNTS which allows us
to provide a better indication of the tester’s capabilities across measurement ranges.
A COUNT refers to the lowest resolution of the display for a given measurement
range. For example, if the resolution for voltage is 1V then 2 counts = 2V.
