37
Voltage: The voltage that is applied to the High Voltage and Return Terminals during
a test.
Max Lmt: The maximum current or resistance threshold that triggers a failure when
exceeded.
Min Lmt: The minimum current or resistance threshold that triggers a failure when not
exceeded.
Ramp Up: The length of time that is allowed for the test voltage to climb from 0 to the
programmed test voltage.
Dwell: The length of time that is allowed for the programmed test voltage to be
applied.
Delay: The length of time that the programmed test voltage is applied but no judgment
of the set parameters is made. Judgment of the parameters is not made until the end
of the delay time.
Ramp Dn: The length of time that is allowed for the test
voltage to decay from programmed test voltage to 0.
Arc Sense: The maximum allowable threshold for
arcing. The numbers 0 through 9 correspond to the
different arc sensitivity levels, 1 being the least
sensitive, 9 being the most sensitive, and 0 being OFF.
After the “+” or “-” soft keys are pressed, the arc
sensitivity will automatically adjust to the new setting.
Arc detection is not required for testing, but may be
used as a diagnostic tool. Contact Associated
Research, Inc. or visit our website for more information.
Frequency: This parameter is available in AC testing
only and may be toggled between 50 and 60 Hz.
Continuity: This function checks for a connection between the Cont. Check and
Return Terminals. This is a basic DC continuity check that measures the continuity
value but does not display it. Continuity may be turned ON or OFF.
Offset: Used during the Continuity test to factor out test lead and fixturing resistance.
Connect: This function will connect or link the current test step to the next test step.
The third test step in a memory will not have this function because it is the last test
step of the memory location.
Associated Research, Inc
provides detailed
whitepapers and articles
on our website. Check
out the following link for
more information on Arc
Sensitivity:
http://www.asresearch.co
m/events-
training/articles.aspx
