page 10
1.Programming
Select units, reverse display and set the high/low setpoints if
required, using the steps on pages 6-9.
2.Attachments
Hand tighten attachments to the shaft. Do not use tools!
3.Measurement Mode
Real Time Measurement
Press ON/OFF to turn on the gauge. The gauge automatically
enters real time mode and displays transient force values.
Peak Measurement
Press
ON/OFF to turn on the gauge. Press PEAK to capture
peak measurements. In Multi display mode ‘P’ is displayed and in
Single display mode ‘Peak’ is displayed. Peak force values do not
change until a higher value is measured. Press
PEAK again to
return to real time.
OPERATION
6
‘Or Peak’ is the factory default and captures either peak com-
pression or tension measured during a test.
‘And Peak’ captures both peak compression and peak ten-
sion (See page 34 for programming instructions).
When ‘And Peak’ is programmed press
PEAK and ‘+P’ is dis-
played. Press
PEAK again and ‘–P’ is displayed.
‘+P’ displays the compression peak captured during a test;
press
PEAK to display the tension peak.
‘–P’ displays the tension peak captured during a test; press
PEAK to display the compression peak.
4.Tare and Zero
‘All Reset’ is the factory default and tares and zeroes the display.
Press
ZERO to zero the display and tare the weight of a preload
or attachment.
If you need to zero without tare see page 41 ‘Peak Only’.
