4.11 CLEARANCE REQUIREMENTS FOR THE OUTDOOR UNIT.
Installation of a single outdoor unit
When the air outlet is opposite the wall
When 3 sides of the outdoor unit are blocked by the wall
e t
op of the outdoor unit and the air outlet are opposite
t
he wall
e top of the outdoor unit and the air outlet are towards
t
he wall
When the front and rear parts of the outdoor unit are
towards the wall
When the air outlet is towards the wall
300 or more
300 or more
600 or more
1500 or more1500 or more 300 or more
1500 or more
300 or more
300 or more
600 or more
2000 or more
(Unit: mm)
