Chapter 3 Environment description and installation
3-19
SW1 and SW2 function description
SW1 Type of external signal Remarks
NPN input (SINK)
PNP input (SOURCE)
Factory default
SW2 Type of external signal Remarks
0~10Vdc analogue signal
4~20mA analogue signal
Effective when
A01=2 (external analogue
input signal from control
terminals TM2)
V
I
V
I
