IMO iDrive - Page 57

Chapter 4 Software index
4-24
b55 / b56 = 004: Frequency detection Fout <b56
(A00)
(b56)
(b56)
b58 Output Current reached set value
b59 Output Current detection time
b55: Output current detection value > b58
b60: Output current detection value > b58
b58: Set value (000-100%) of motor rated current b09
b59: Set value (00.0-25.5s)
When set value is 015
time (s)
100%
b58
Out
p
ut current
b
59
b55=15
or
b60=15
RY Operation
ON
b
59
