Chapter 4 Software index
4-25
b60 Multi-function output transistor T+, T- (Option card
000: Inverter output on - RUN
001: Frequency reached (Preset target frequency ± b57)
002: Frequency reached (Preset output frequency level (b56) ±b57)
003: Frequency Detection (>b56)
004: Frequency Detection (<b57)
005: Fault output
006: Auto restart
007: Momentary power loss
008: Emergency Stop (E.S.)
009: Base Block (b.b.)
010: Motor overload protection
011: Inverter overload protection
012: xxx Not used xxx
013: Power On
014: Communication error
015: Output current detection
Note: Frequency priority: Jog→ Preset frequency →External analog frequency signal
Refer to parameter b55 description for more details.
b61 AIN signal select
000: 0~10V/0~20mA
001: 2~10V/4~20mA
Note: Set switch SW2 (V/I signal select) on inverter control board to required position
b61 = 000: 0~10V/0~20mA
b61 = 001: 2~10V/4~20mA
b62 AIN Gain (%) 000 - 200
b63 AIN Bias (%) 000 - 100
1.) b64 = 000: 0V (4mA) corresponding to lower frequency limit, 10V (20mA) corresponding to upper
frequency limit.
2.) b64 = 001: 10V (20mA) corresponding to lower frequency limit, 0V (4mA) corresponding to upper
frequency limit.
Fig (1) example settings below: Fig (2) example settings below:
b62 b63 b64 b65 b62 b63 b64 b65
A 100% 050% 000 000 C 100% 050% 000 001
B 100% 000% 000 000 D 100% 000% 000 001
