Chapter 6 Peripherals
6-2
6.1.2 EDX-232 option card and cable
EDX-232 connection diagram
1.8 m
RS-232
iDrive
M
EDX-232
CON302 (12P)
SINGLE/THREE-PHASE
POWER SUPPLY
L1 (L) T1
L2 T2
L3 (N) T3
