Chapter 6 Peripherals
6-3
6.1.3 EDX-MP option card (Copy Unit/ Memory pack)
EDX-MP connection diagram
L1 (L) T1
L2 T2
L3 (N) T3
iDrive
EDX-MP
CON302 (12P)
M
SINGLE/THREE-PHASE
POWER SUPPLY
