8 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
General Specifications
GENERAL SPECIFICATIONS
CRANE RATING Model 5525 - 55,000 ft-lb (7.6 tm)
Model 6025 - 60,000 ft-lb (8.3 tm)
Model 6625 - 66,000 ft-lb (9.1 tm)
HORIZONTAL REACH (From centerline of
rotation)
25'-4" (7.7 m)
HYDRAULIC EXTENSIONS (2) 78" & 78" (198.1 cm & 198.1 cm)
LIFTING HEIGHT (From base of crane) 26'-7" (8.1 m)
CRANE WEIGHT 2,350 lb (1,066 kg)
OUTRIGGER SPAN (Required option)
Crane Side (From centerline of chassis)
90" (228.6 cm)
Opposite Crane Side (From centerline of
chassis)
48" (121.0 cm)
CRANE STORAGE HEIGHT 40" (101.6 cm)
MOUNTING SPACE REQUIRED (Crane base) 20" x 21" (50.8 cm x 53.3 cm)
OPTIMUM PUMP CAPACITY 10 U.S gpm (37.9 l/min)
SYSTEM OPERATING PRESSURE 3,000 psi (206.8 bar)
CENTER OF GRAVITY
Horizontal from Centerline of Rotation
41" (104.1 cm)
Vertical from Bottom of Crane Base
22" (55.9 cm)
TIE-DOWN BOLT PATTERN (8 bolts) 14-3/4" x 14-3/4" (37.5 cm x 37.5 cm)
ROTATIONAL TORQUE 9,000 ft-lb (1.2 tm)
* Crane rating (ft-lb) is the rated load (lb) multiplied by the respective distance (ft) from centerline of
rotation with all extensions retracted and lower boom in horizontal position.
PERFORMANCE CHARACTERISTICS
SPECIFICATIONS SPEED
ROTATION 400° (7.0 rad.) 33 seconds
LOWER BOOM ELEVATION -5° to +78° (-0.09 to +1.31 rad) 11 seconds to raise
13 seconds to lower
EXTENSION CYLINDERS
(2)
78" & 78" (198.1 cm & 198.1
cm)
23 seconds to extend
32 seconds to retract
PLANETARY GEAR LINE
SPEED
55 feet per minute (2nd wrap)
