12 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
Capacity Chart, 5525
IOWA MOLD TOOLING CO., INC.
BOX 189, GARNER, IA 50438-0189
TEL: 641-923-3711 FAX: 641-923-2424
70396149
• Values in the box indicate the use of 2-
part line is required..
The weight of load-handling devices is part
of the load lifted and must be deducted from
the rated capacity.
xxxx lb
xxxx kg
78°
60°
45°
30°
15°
0°
10500
4760
7760
3520
6290
2850
5515
2500
4990
2260
4460
2020
6940
3150
3635
1650
2815
1280
2400
1090
2100
950
1840
830
9500
4310
4930
2240
3870
1755
3330
1510
2960
1340
2600
1180
12'-4"
(3.75 m)
18'-10"
(5.75 m)
25'-4"
(7.72 m)
• Maximum 1-part line weight is 5500 lb
(2500 kg).
• See reduced capacity chart for
additional information when applicable.
