IMT 5525 User Manual

34 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
Base & Mast Assemblies
Base & Mast Assembly (99903692) (Primary configuration)
B
3
22
16
24
27
10
11
27
9
32
13
12
33
17
8
6
2
8
17
5
9
28
28
35
36
37
9
9
9
27
25
26
27
7
42
41
44
43
4
5
38
4
USE BLUE THREAD LOCKER
USE BLUE
THREAD
LOCKER
USE ANTI-SEEZ
TORQUE TO
280 FT-LB
23,29
(4 PLCS)
23,30 (18 PLCS)
19 (4 PLCS)
14,18
(2 PLCS)
15,20,21
(4 PLCS)
ITEMS 41-44 ARE PART OF DECAL KITS,
AND NOT USED ON 6625 MODEL CRANES.
DETAIL B
SCALE 0.31:1
BASE & MAST ASSEMBLY PARTS LIST (99903692)
ITEM PART # DESCRIPTION QUANTITY
1. 51719131 KIT-HARDWARE 1
2. 51719127 VALVE BODY ASY W/FITTINGS 1
3. 52718741 PIN 1
