Chapter 4 Parts 105
DECAL PLACEMENT (IF NOT SHOWN ON CRANE)
ITEM # PLACEMENT
18,20,21,37 AT OR NEAR REMOTE HANDLE STORAGE POINT
2 ON OUTRIGGERS OR BUMPER GUSSET
7 2 ON REAR OUTRIGGERS, 2 ON SIDEPACK FRONT WALLS
9 AT OR NEAR DRIVELINE
8,12 ON ALL FOUR SIDES OF CARRIER VEHICLE
11 ON OIL RESERVOIR
5,25 ON TOP OF BASE OVER WORM DRIVE
31 INSTALL AT REAR OF CRANE BASE AFTER CRANE IS
MOUNTED ON BODY
DECAL PART NUMBERS FOR 5525 - 6025 - 6625 CRANE MODELS
ITEM PART # DESCRIPTION QUANTITY
REF 95719347 DECAL KIT, TELE COMMON (SHEET) 1
REF 95719348 DECAL SET, BODY COMMON (BAG) 1
REF 95719358 DECAL SET, 6025 MODEL SPECIFIC (PRIMARY
CONFIGURATION)
1
REF 95719403 DECAL SET, 5525 MODEL SPECIFIC (PRIMARY
CONFIGURATION)
1
REF 95719404 DECAL SET, 6625 MODEL SPECIFIC (PRIMARY
AND ALTERNATE CONFIGURATIONS)
1
REF 95719481 DECAL SET, 5525 MODEL SPECIFIC (ALTERNATE
CONFIGURATION)
1
REF 95719482 DECAL SET, 6025 MODEL SPECIFIC (ALTERNATE
CONFIGURATION)
1
1. 70029251 DECAL, IMT DIAMOND 2
2. 70391598 DECAL, WARNING, MAN O/R 2
3. 70391612 DECAL, GREASE WEEKLY (LEFT) 5
4. 70391613 DECAL, GREASE WEEKLY (RIGHT) 2
5. 70392399 DECAL, LUBRICATION 1
6. 70392524 DECAL, ROTATE WHILE GREASING 1
7. 70392864 DECAL, OUTRIGGER STAND CLEAR 4
8. 70392868 DECAL, DANGER LOADLINE (TRUCK) 4
9. 70392891 DECAL, DANGER DRIVELINE 1
10. 70393860 DECAL, LOAD BLOCK RATING 2
11. 70394189 DECAL, OIL RESERVOIR 1
12. 70394445 DECAL, DANGER ELECTROCUTION 4
13. 70395324 DECAL, ASME/ANSI B30.5 1
14. 70395670 DECAL, CAUTION DOWNHAUL WT. 2
15. 70396655 DECAL, ID 6025 2
70396697 DECAL, ID 5525 2
70396698 DECAL, ID 6625 2
16. 70396096 DECAL, CAPACITY PLACARD, 6025 1
70396149 DECAL, CAPACITY PLACARD, 5525 1
70396054 DECAL, CAPACITY PLACARD, 6625 2
17. 70396631 DECAL, MANUAL OVERRIDE 1
18. 70396613 DECAL, DANGER CRANE OPERATION 1
19. 70394166 DECAL, MANUAL OVERRIDE (70396632 THRU 1-
31-06)
1
