10 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
WINCH
The 5,500 lb planetary winch is powered using a high-torque hydraulic motor. The lifting
capacity of the winch is 5,500 lb (2,495 kg) one-part line. Maximum two-part line winch capacity
is 10,500 lb (4,762 kg). The winch is equipped with 100 ft (30.5 m) of 7/16" (1.1 cm) 6x25 FW
PRF RRL IWRC XIPS wire rope. A compact, anti-two block device is included to prevent the
lower block or hook assembly from coming in contact with the boom sheave assembly. The
winch meets ANSI B30.5 standards.
MINIMUM CHASSIS SPECIFICATIONS
CHASSIS STYLE Conventional Cab
WHEELBASE 154" (391 cm)
CAB-TO-AXLE 84" (213 cm)
RESISTANCE TO BENDING
MOMENT
800,000 in-lb (9,217 kg-m)
FRAME SECTION MODULUS 16 cubic inches (262.2 cc)
FRAME YIELD STRENGTH 50,000 psi (3,447 bar)
FRONT AXLE RATING (GAWR) 9,000 lb (4,082 kg)
REAR AXLE RATING (GAWR) 17,000 lb (7,711 kg)
GROSS VEHICLE RATING 26,000 lb (11,793 kg)
TRANSMISSION 5 speed
In addition to these specifications, heavy duty electrical and cooling systems are required. It is
recommended that the vehicle be equipped with an engine tachometer, auxiliary brake lock, and
power steering.
NOTES:
1 GAWR means Gross Axle Weight Rating. GAWR is dependent on all vehicle components
including axles, tires, wheels, springs, brakes, steering and frame strength meeting the
manufacturer's recommendations. Always specify GAWR when purchasing a truck.
2 Minimum axle requirements may increase with use of diesel engines, longer wheelbase or
service bodies. Contact the factory for more information.
3 Weight distribution calculations are required to determine final axle loading.
All chassis, crane and body combinations must be stability-tested to ensure stability per ANSI
B30.5
Iowa Mold Tooling Co., Inc. reserves the right to change specifications and design without notice.
