Chapter 4 Parts 31
CYLINDER IDENTIFICATION
To insure proper replacement parts are received, it is necessary to specify the complete
number/letter sequence for any part requested. Part numbers may be cross checked by
comparing the stamped identification on the cylinder case (See figure below) against the
information contained in the service manual. You must include the part number stamped on the
cylinder case when ordering parts.
CYLINDER
PART NUMBER
LOCATION
WELDMENT IDENTIFICATION
Each of the major weldments - base, mast, inner boom, outer boom, extension boom and
outrigger weldments bear a stamped part number. Any time a major weldment is replaced, you
must specify the complete part number as stamped on the weldment. The locations of the part
numbers are shown in the Crane Reference Section.
ORDERING REPAIR PARTS
When ordering replacement parts:
1 Give the model number of the unit.
2 Give the serial number of the unit.
3 Specify the complete part number. When ordering cylinder parts, or one of the main
weldments, always give the stamped part number.
4 Give a complete description of the part.
5 Specify the quantity required.
