44 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
73733947 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
77040488 COIL FOR PROP VALVE 3W2P
3. 73540167 VALVE, SPOOL 4
77040489 COIL FOR SPOOL VALVE 4W3P
4. CAVITY PLUG, 4W 1
5. MANIFOLD 1
6. PLUG, EXPANDER, 7MM 4
7. PLUG, SAE #4 ZL 6
8. PLUG, SAE #4 1
9. PLUG, SAE #6 ZL 1
10. NAME PLATE 1
11. 73540191 VALVE, SPOOL, 2W N.O. (INCL. 12) 1
12. 77040154 COIL, 12 VDC 1
94396851 SEAL KIT FOR SPOOL VALVE 2W N. O.
13. 73540169 ORIFICE DISK, Ø.030 1
14. SHUTTLE VALVE 1
15. COUNTERBALANCE VALVE 2
16-25. I.D. TAGS 1
26. #10 SAE PLUG 1
27. 73540192 VALVE, SPOOL 2W N.C. (INCL. 28) 1
28. 77040442 COIL, 12V DC 1
94396853 SEAL KIT FOR SPOOL VALVE 2W N.C.
29. CAP SCREW, SOCKET HEAD #10-24 X 1-3/4" 16
30. CAP SCREW, SOCKET HEAD #10-24 1-1/4" 4
31. CABLE SEAL 16
32. TERMINAL, FEMALE PIN 16
#4 SAE PLASTIC PLUG 2
#6 SAE PLASTIC PLUG 4
#8 SAE PLASTIC PLUG 6
33. SPOOL VALVE 1
REV. F 20051205
