Chapter 4 Parts 59
NOTE:
ITEM 45, 70396627, IS A BOOM LENGTH INDICATOR DECAL. EACH RED SEGMENT AND EACH WHITE
SEGMENT IS 6-INCHES LONG, SO A RED AND WHITE PAIR OF SEGMENTS IS 1-FOOT LONG. BY COUNTING
THE NUMBER OF RED AND WHITE PAIRS, THE OPERATOR CAN DETERMINE HOW FAR THE BOOM IS
EXTENDED, AND THUS, THE CAPACITY AT THAT PARTICULAR REACH.
BOOM ASSEMBLY PARTS LIST (99903624)
ITEM PART # DESCRIPTION QUANTITY
1. 51718758 HARDWARE KIT 1
2. 51713168 CORD REEL ASM 1
3. 52718005 TUBE WELDMENT- ANTI TWO BLOCK 1
4. 52719442 BOOM-LOWER WLDMT ASM 1
5. 52718672 BOOM-1st STAGE EXT WLDMT 1
6. 52718673 BOOM-2nd STAGE EXT WLDMT 1
7. 60030336 WEAR PAD-RC 2
8. 60030337 WEAR PAD-RND 4
9. 60105544 PLATE-ANGLE PLASTIC 2
10. 72601757 STUD .50-13X 2.00 NC GR5 STL (PART OF #1 ) 4
11. 60122358 PLATE-SINGLE SHEAVE 1
12. 60122982 WEAR PAD 1
13. 60122983 WEAR PAD-RC 1
14. 60122984 WEAR PAD-RND 1
15. 60122985 WEAR PAD-RND 4
16. 60122986 PIN-TYPE A 1.25X 7.00 ( 6.31) 1
17. 60126259 RETAINER 2
18. 70034381 SUPPORT 4
19. 70034382 CAP- GREASE ZERK (PART OF #1) 2
20. 70146096 SPRING 0.62 X 2.50 X 14 GA. (PART OF #1) 2
21. 70396121 CAP-PLSTC (PART OF #1) 2
22. 71410928 CYLINDER ASSEMBLY 1
23. 72053508 ZERK-NPT .12 (PART OF #1) 2
24. 72060007 CAP SCR .25-20X 1.75 HH GR5 Z (PART OF #1 ) 3
25. 72060055 CAP SCR .38-16X 3.50 HH GR5Z (PART OF #1) 2
26. 72060098 CAP SCR .50-13X 3.50 HH GR5 Z (PART OF #1) 1
27. 72062080 NUT .50-13 HEX NYLOCK (PART OF #1) 1
28. 72062103 NUT .38-16 HEX NYLOCK (PART OF #1) 4
29. 72062104 NUT .25-20 HEX NYLOCK (PART OF #1) 3
30. 72063001 WASHER .25 FLAT (PART OF #1) (WAS 6) 2
31. 72063003 WASHER .38 FLAT (PART OF #1) 10
32. 72063005 WASHER .50 FLAT (PART OF #1) 6
33. 72063035 MACHY BUSHING 1.25X10 GANR (PART OF #1 ) 2
34. 72063049 WASHER .25 LOCK (PART OF #1) (WAS 2) 3
35. 72063116 WASHER .75 N FLAT H ASTMF (PART OF #1) 1
37. 72066145 HAIR PIN .19 ZINC (PART OF #1) 1
38. 72601484 CAP SCR .75-10X 1.75 HH GR8Z (PART OF #1) 1
39. 72661312 CLAMP- .50 LOOP CUSHIONED (PART OF #1) 1
40. 77041459 SWITCH-LIMIT 1
41. 77044468 CONNECTOR- .50 STR RLF .12-.25 1
