94 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
31712740 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
1. 3B205010 CYLINDER 2
2. 51394931 HOSE-FF 1/2X98 OAL 1
3. 51395552 HOSE-FJ 1/4X135 OAL 2
5. 51714813 VALVE BANK, 2 SECT (INCLUDES #40) 1
6. 51396280 HOSE-FJ 1/4X96 2
7. 52070138 PIN WELDMENT 1
8. 52712735 ARM, ADJUSTABLE 1
9. 52712736 ARM, STATIONARY 1
10. 60010351 SPRING "T" PIN 1
11. 51396184 HOSE-FF 1/2X159 OAL (8-8) (PART OF #51) 1
12. 51396282 HOSE-FF 3/4 X51 OAL (12-12) (PART OF #51) 1
13. 72053758 ELBOW #4MSTR #4MJIC 90° 2
14. 72053764 ELBOW #10MSTR #8MJIC 90° 1
15. 72060025 CAP SCR 5/16-18X1 HHGR5Z 3
16. 72060107 CAP SCR 1/2-13X8 HHGR5 1
17. 72060155 CAP SCR 5/8-11X3.5 HHGR5 4
18. 72060833 SCR-THD CUT 5/16-18X3/4 HWH-1 (SEE
NOTE)
2
19. 72062080 NUT 1/2-13 HEX NYLOC 1
20. 72062091 NUT 5/8-11 HEX NYLOC 4
21. 72063002 WASHER 5/16 FLAT 5
22. 72063005 WASHER 1/2 FLAT 2
23. 72063027 MACHY BUSHING 5/8X14 GA NR 2
24. 72066185 COTTER PIN 1
25. 72066582 CLAMP-UMP 20 (SEE NOTE) 2
26. 72532358 ADPTR #8MSTR #8MJIC 1
27. 72532365 ADPTR #10MSTR #12MJIC 1
28. 72531205 TEE-MALE JIC 3/4-16 1/2 TUBE 1
29. 72532658 ELBOW #8MJIC #8FJIC SW 1
35. 72532696 ELBOW #12MJIC #12FJIC SW 1
37. 76391511 DECAL-UP & DOWN STAB. R&L 1
38. 89034049 SPIRAL WRAP, BLK (SEE NOTE) 4'
39. 99900644 MANUAL-AUX OUTRIGGER 1
40. 51731580 HANDLE ASM (INCL. 34-41) (PART OF 5) 2REF
41. 70142648 PIVOT-LEVER (PART OF #40) 2REF
42. 70142650 LEVER SUPPORT (PART OF #40) 2REF
43. 70142651 LEVER-CONTROL HANDLE (PART OF #40) 2REF
44. 71392269 KNOB-CONTROL HANDLE (PART OF #40) 2REF
45. 72062021 NUT 5/16-18 HEX JAM (PART OF #40) 2REF
46. 72062024 NUT 1/2-13 HEX JAM (PART OF #40) 2REF
47. 72066162 COTTER PIN (PART OF #40) 4REF
48. 72661204 CLEVIS PIN (PART OF #40) 4REF
49. 72532972 ADPTR #8MJIC #12FJIC 1
50. 72532980 ADTPR PR SW IN-LINE JIC 3/4 1
51. 52712734 O/R HOUSING 7X5 1
52. 70392864 DECAL-DANGER O/R STAND CLEAR 2
53. 70392867 DECAL-DANGER O/R (MOVING) 1
54. 71392257 DECAL-O/R POWER DOWN SS 1
55. 71392277 DECAL-O/R POWER OUT 1
56. 72533567 ELBOW #4MSTR #4MJIC XLG 2
REV. E 20031117
To Next Page
