4. WIRING DIAGRAMS:
4.1 INDESIT ELECTROMECHANICAL VENTED MODELS
11
SWITCH RATINGS REVERSING TIMERS
Type CONTACT /
TERMINAL
RATING COMPONENT
SWITCHED
MAX.
CURRENT
PEAPSA 2 - 1
Invensys ZBN 2 - 1 16 (4) A MOTOR &
HEATER
12 A
Invensys EC B1 - B3
Elbi 5000 B5 - B3
PEAPSA 1 - 10
Invensys ZBN 1 - 10
Invensys EC A9/A10 - A11 16 (4) A HEATER 12 A
Elbi 5000 A3 - A2
PEAPSA 4 - 3,5
Invensys ZBN 4 - 3,5 16 (4) A MOTOR (Reversing) < 2 A
Invensys EC B9/B10 - B11, B12
Elbi 5000 C3 - C1, C2
12
MAIN TIMER SEQUENCE REVERSING TIMERS
PROGRAMME CAM
Timer Markings
160
140
120
100
80
60
40
20
10
Actual time
163
160
143
122
102
81
61
41
20
12
10
switch
switch
no.
336°
330°
294°
252°
210°
168°
126°
84°
42°
24°
21°
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58
timer motor 2 - 1
heater 1 -10
Note *1 the programme cam must advance to step 1 before stopping
REVERSING CAM
switch
switch
no.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58
15s *2 15s
