1.4 TECHNICAL DATA - CONDENSER/VENTED DRYERS
MODELS
FEATURES
ENERGY CLASS
NOISE LEVEL
DIMENSIONS
DRUM SPEED
MAXIMUM LOAD
DELAY TIMER
DOOR LATCH RELEASE
HEATING ELEMENTS
THERMOSTATIC
SAFETY DEVICES
MOTOR
SPECIFICATIONS
MOTOR CAPACITOR
ACCESSORIES
TIMER
PCB
DRYING SYSTEM
ASD70CEX
Electronic control and di-
splay interface
C
72 dBA
H 850 mm
W 595 mm
D 584 mm
Weight 41 kg
7 kg
10 hours 1 hour steps
Push-Push
2300W - 230V
Resettable thermostat
106 °C
On e- sh ot the r mo st at
143 °C
Single phase with start
capacitor - 2-pole - 2800
rpm
7µF
X
Condenser system
ISL70CNL
Electronic control and LED
interface
C
72 dBA
H 850 mm
W 595 mm
D 584 mm
Weight 41 kg
7 kg
12 hours 3 hour steps
Push-Push
2300W - 230V
Resettable thermostat
106 °C
On e- sh ot th er mo st a t
143 °C
Single phase with start
capacitor - 2-pole - 2800
rpm
7µF
X
Condenser system
AS60VEX
Rx/Lx rotation, End-of-pro-
gramme alarm
C
72 dBA
H 850 mm
W 595 mm
D 584 mm
Weight 35 kg
55 rpm Rx/Lx
6 kg
12 hours
Handle
2200 W 230V
1100 W 230V
Resettable ther mostat
120 °C
On e- sh ot th er mo st at
150 °C
Single phase induction
- 2-pole - Start Capacitor
- 2800 rpm - reversible
7,5 µF
Venting kit
Programme duration 140
min including 7.5 min for
drum cooling 2 ECO pro-
grammes and anti-crease
Vented system
