5 sErvicEability
Service Manual
Yate Production Dryers
Edition
2006.09.21
2. Raise the drum and remove the air duct
Air duct
1. Remove the top, control panel, side panels, front
panel and motor
Front bearings
1. Detach the air duct
2. Replace the 4 bearings
Rear bearing
1. Remove the guard of the rear bearing
2. Undo the screw securing the bearing assembly
