5 sErvicEability
Service Manual
Yate Production Dryers
Edition
2006.09.21
2. Release the two clips securing the cover of the
reservoir to the base
3. Release the reservoir from the base (Rx and
Lx)
4. Replace the pump / switch or float
Pump switch and float
1. Remove the Lx side panel
3. To replace the heating element, first disconnect
the power cable from the mainboard
Heater unit - safety thermostats - NTC sensors
1. Remove the guard from the heater unit
2. Disassemble the unit, undoing the two screws
securing it to the guard
