5 sErvicEability
Service Manual
Yate Production Dryers
Edition
2006.09.21
5.5. DISASSEMBLY:
Top:
5.5.1 ELECTRONIC CONDENSER DRYER COMPONENTS:
1. Remove the 2 screws securing the top to the rear
panel.
3. Slide the panel back to free it from the lugs at the
bottom
Side panels:
2. Slide the top back and lift.
1. Remove the top.
2. Remove the screws securing the side panel to
the rear panel (on certain dryers, there is a screw
under the base)
