5.2.1 AUTOTEST WITH LED INTERFACE
The test programme requires the use of the hardware key and test fuse, which has a resistance of approx
270k between the two magnets. The fuse is installed between the conductivity sensor and the drum.
To set up the test programme, close the door and press the button on the HW key. Switch on the machine,
and press the TEST button on the HW key to activate the test programme.
N.B. The dryer will go into autotest mode the first time it is powered up after being programmed.
1. Power up the dryer to activate the autotest
The ON-OFF
Led lights up
The
delayed start and 3h delay Leds light up
The drum rotates clockwise
Check the motor
2. Press Delayed Start
The delayed start Led blinks and the buzzer sounds
The
Drying/6h delay Led lights up and the heating element warms to low (half) heat
Check the low heat temperature
3. Press the alarm button
The
alarm Led and the Cooling/9h delay Led light up The heating element warms to full heat
Check the full heat temperature
4. Press the Full Heat button
The Full heat and Crease Care (end of programme/12h delay)
Led lights up.
The drum rotates counterclockwise, the heating elements switch off and the buzzer sounds
Check opposite rotation of motor and deactivation of heating elements If the drum stops turning
after 3 seconds, there is a problem with the conductivity sensor or the magnetic connector is
not coupled.
5. Open the door and check
Counterclockwise rotation ceases and the
clean filter Led lights up
Check the door microswitch
6. Close the door, turn the selector to position 4 (3 hours), and press Start/Cancel
When the status Leds light up, return the selector to position 0 (12 hours) and check that all the Leds
are alight
7. Press the ON-OFF button to switch off the dryer
5.2.2 AUTOTEST WITH DISPLAY INTERFACE
1. The test programme requires the use of the hardware key and test fuse, which has a resistance of approx
270k between the two magnets. The fuse is installed between the conductivity sensor and the drum.
To set up the test programme, close the door and press the button on the HW key. Switch on the machine,
and press the TEST button on the HW key to activate the test programme.
N.B. The dryer will go into autotest mode the first time it is powered up after being programmed.
2. Power up the machine and make certain the display reads OFF.
Press Autotest on the HW key to activate the test programme
The ON-OFF Led lights up and the message Test blinks in the display
The Anti-crease icon lights up (start of programme)
The drum rotates clockwise
Check the motor
