InFocus IN3136a User Manual

— iii —
Projector Installation Notice
 Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees. In addition, the projector should
not be installed in any other way except desktop and ceiling mount positions. Otherwise lamp life
could decrease dramatically, and may lead to other unpredictable damage.
 Allow at least 50 cm (16.69 inch) clearance around the exhaust vent.

 Ensure that the intake vents do not recycle hot air from the exhaust vent.
 When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
 All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.
Minimum 500mm
(19.69 inch)
15 °
-15 °
Minimum 500mm
(19.69 inch)
Minimum 500mm
(19.69 inch)
Minimum 500mm
(19.69 inch)
Minimum 300mm
(11.81 inch)
Minimum 100mm
(3.94 inch)

InFocus IN3136a Specifications

General

Noise Level	37 decibels
White Brightness	4500 lumens
Resolution	768p
Native Resolution	1280 x 800
Contrast Ratio	8000:1
Aspect Ratio	16:10
Throw Ratio Range	1.45 - 2.17
Keystone Effect	yes
3D	yes
Minimum Screen Size	25.7 inches
Maximum Screen Size	320.9 inches
Focus Adjustment	manual
Optical Zoom	1.5x
Minimum Distance	3.94 feet
Maximum Distance	32.8 feet
HDMI Ports	2
USB Ports	1
Video Input	composite video, hdmi, s-video, vga
Inputs	3.5mm audio, composite video, hdmi, rca, s-video, vga
Built In Speakers	yes
Speakers Output	10 watts
Remote Control	yes
OS Compatibility	mac, windows

Weight and Dimensions

Depth	10.3 inches
Height	4.8 inches
Width	11.2 inches
Net Weight	6.94 pounds
