APPENDIX I
Serial Communication
The following table describes the serial communication configuration that should be used when
interfacing to CLI via the serial port.
Windows HyperTerminal or ProComm are two tools that can be used to send CLI commands across
the serial port.
Setting
Value
Bits per second
19200
Data bits
8
Parity
None
Stop bits
1
Flow control
None
Emulation
VT100
Control Command Structure
Header code
Command code
Data code
End code
HEX
28
Command
Data
29
ASCII
(
Command
Data
)
No
Function
Command
RW
Min
Max
Default
Step
Parameter
1V
AC Power On
(Auto power on)
APO
RW
0
1
0
1
0:Disable; 1:Enable
3V
Aspect Ratio
ARZ
RW
0
5
0
1
0:Fill
1:4:3
2:16:9
3:Letterbox
4:Native
5:2.35:1
4V
Auto Image
AIM
W
n/a
1
1
1
1:Enable
5V
Auto Off Time
AOT
RW
0
36
6
1
0:Never
1~36 * 5 = ? min
1:5min
6:30min (Default)
36:180min
6V
Auto Source
ASC
RW
0
1
1
1
0:Disable; 1:Enable
7V
Blank Screen
BLK
RW
0
1
0
1
0:Disable; 1:Enable
9V
Brightness
BRT
RW
0
100
50
1
Valid only when Display
Mode = User
11V
Projection
(Ceiling mode)
CEL
RW
0
3
0
1
0:Front
1:Rear
2:Ceiling
3:Ceiling+Rear
12V
Closed Captions:
Non-
Muted
CLC
RW
0
1
0
1
Off
On (CC1)

InFocus IN3136a Specifications

General

Noise Level	37 decibels
White Brightness	4500 lumens
Resolution	768p
Native Resolution	1280 x 800
Contrast Ratio	8000:1
Aspect Ratio	16:10
Throw Ratio Range	1.45 - 2.17
Keystone Effect	yes
3D	yes
Minimum Screen Size	25.7 inches
Maximum Screen Size	320.9 inches
Focus Adjustment	manual
Optical Zoom	1.5x
Minimum Distance	3.94 feet
Maximum Distance	32.8 feet
HDMI Ports	2
USB Ports	1
Video Input	composite video, hdmi, s-video, vga
Inputs	3.5mm audio, composite video, hdmi, rca, s-video, vga
Built In Speakers	yes
Speakers Output	10 watts
Remote Control	yes
OS Compatibility	mac, windows

Weight and Dimensions

Depth	10.3 inches
Height	4.8 inches
Width	11.2 inches
Net Weight	6.94 pounds
