Evolve System Operator Manual
Section 4: Device Description
Return to the Main Menu to select the Applicator.
Figure 4-8: Transform Treatment Screen
This indicator shows elapsed time from the beginning of
treatment activation.
The device is automatically set to start with PREHEAT sequence:
the system will deliver the lowest energy level to preheat the
unit and to bring skin and electrodes to the same temperature
This button activates the treatment. After pressing the ‘Start’
button, the system is in ‘Active’ mode. The icon will then change
to ‘Pause’ and clicking on it will pause the treatment (‘Pause’
mode). The ‘Elapsed Time’ counter will not reset while pausing
the treatment.
Any attempt to change the settings during treatment, switches
the system to Pause mode.
This button Stops the treatment and switches the system to
Standby mode. The ‘Elapsed Time’ counter resets.
RF power is changed within the limits allowed for the connected
Applicator. Power level settings are changed from 20 to 50
energy levels. The System starts up at minimal power level
setting.
This indicator shows the cut-off temperature, which is
adjustable from 35 to 43
o
C. This indicates measured
temperature at which the RF delivery is stopped.
This indicator shows time when RF energy is applied sequentially
to the Applicators.
