EC RUN
Green light off
EtherCAT state
machine status:
INIT=initialization
None
Green light flashes
quickly
EtherCAT state
machine status:
PREOP=Pre-operation
None
Green light flashes
slowly
EtherCAT state
machine status:
SAFEOP=safe
operation
None
Steady green
EtherCAT state
machine state: OP=
run
None
EC ERR
Red light off
EtherCAT
communication is
trouble-free
None
Red light is always
on
EtherCAT
communication is
faulty
Check the fault code displayed on the
rectifier panel
EC LA
Yellow light off
Nothing with the
previous EtherCAT
device
connection
None
Yellow light is always
on
Already connected
with the previous
EtherCAT device
connection
None
Green light off
No data interaction
on the network port
None
Flashing green
Data exchange
through the network
port
None
