13.7 Shielded Cable
13.7.1 Requirements for Shielded Cable
The shielded cable must be used to satisfy the EMC requirements of CE marking. Shielded cables are classified into three-
FRQGXFWRUFDEOHDQGIRXUFRQGXFWRUFDEOH,IFRQGXFWLYLW\RIWKHFDEOHVKLHOGLVQRWVXIÀFLHQWDGGDQLQGHSHQGHQW3(FDEOHRUXVH
a four-conductor cable, of which one phase conductor is PE cable.
7KHWKUHHFRQGXFWRUFDEOHDQGIRXUFRQGXFWRUFDEOHDUHVKRZQLQWKHIROORZLQJÀJXUH
PE
PE conductor
and shield
Shield Shield
PE
PE
Shield
To suppress emission and conduction of the radio frequency interference effectively, the shield of the shielded cable is cooper
EUDLG7KHEUDLGHGGHQVLW\RIWKHFRRSHUEUDLGVKRXOGEHJUHDWHUWKDQWRHQKDQFHWKHVKLHOGLQJHIÀFLHQF\DQGFRQGXFWLYLW\DV
VKRZQLQWKHIROORZLQJÀJXUH
Cable core
Internal insulator
Copper braid
Copper shield
,QVXODWLRQMDFNHW
13.7.2 Cabling Requirements
1. The motor cable and PE shielded conducting wire (twisted shielded) should be as short as possible to reduce electromagnetic
radiation and external stray current and capacitive current of the cable. If the motor cable is over 100 meters long, an output
ÀOWHURUUHDFWRULVUHTXLUHG
2. It is recommended that all control cables be shielded.
3. It is recommended that the motor cables, power input cables and control cables be laid in different ducts. To avoid
electromagnetic interference caused by rapid change of the output voltage of the AC drive, the motor cables and other cables
must not be laid side by side for a long distance.
4. ,IWKHFRQWUROFDEOHPXVWUXQDFURVVWKHSRZHUFDEOHPDNHVXUHWKH\DUHDUUDQJHGDWDQDQJOHRIFORVHWR2WKHUFDEOHV
must not run across the AC drive.
5. The power input and output cables of the AC drive and weak-current signal cables (such as control cable) should be laid
vertically (if possible) rather than in parallel.
6. The cable ducts must be in good connection and well grounded. Aluminium ducts can be used to improve electric potential.
7. 7KHÀOWHU$&GULYHDQGPRWRUVKRXOGEHFRQQHFWHGWRWKHV\VWHPPDFKLQHU\RUDSSOLDQFHSURSHUO\ZLWKVSUD\LQJSURWHFWLRQ
at the installation part and conductive metal in full contact.
