Inovance MD500T75G - Page 42

3. Electrical Installation MD500 User Manual
- 42 -
Ƶ
Cable Dimensions and Tightening Torque
)LJXUH7HUPLQDOGLPHQVLRQVRI0'7**
136
16 15 17 16
15
M6 combination screw
7DEOH&DEOHGLPHQVLRQVDQGWLJKWHQLQJWRUTXHRI0'7*3*3
AC Drive Model Rated Input Current (A) Recommended Cable
Diameter (mm
2
)
Tightening
Torque (N·m)
Recommended Cable
Lug Model
MD500T18.5G  10 4.0 GTNR10-6
MD500T22G  16 4.0 GTNR16-6
)LJXUH7HUPLQDOGLPHQVLRQVRI0'7**
16.5
18.4
1820.2
20.2 18.4
161.6
M6 combination screw
RST UVW
POWER MOTOR
BR
(+) (-)
7DEOH&DEOHGLPHQVLRQVDQGWLJKWHQLQJWRUTXHRI0'7**
AC Drive Model Rated Input Current (A) Recommended Cable
Diameter (mm
2
)
Tightening
Torque (N·m)
Recommended Cable
Lug Model
MD500T30G 57 16 4.0 GTNR16-6
MD500T37G  25 4.0 GTNR25-6
