- 101 -
5 Troubleshooting
5
Probable Cause ConrmingMethod Corrective Action
3. Bleeder resistor failure
If an external bleeder resistor is used
(2002-1Ah=1/2), measure resistance
between P and C.
Forbleederresistorspecication,referto
the"1.5BleederResistorSpecication"
section on page 21.
Ifresistanceis"∞",wirebreakingoccursin
the bleeder resistor.
If an external bleeder resistor is used,
replace it with a new one between P and
C.
Set 2002-1Bh (power of external bleeder
resistor) and 2002-1Ch (resistance
of external bleeder resistor) correctly
accordingtothespecicationsoftheused
bleeder resistor.
4. The resistance of the
bleeder resistor is
too large, and energy
absorptionduringbraking
isinsufcient.
Measure the resistance of the external
bleeder resistor between P and C.
Compare the measured value with the
recommended value.
Connect a new external bleeder resistor of
recommended resistance between P and
C.
Set 2002-1Bh (power of external bleeder
resistor) and 2002-1Ch (resistance
of external bleeder resistor) correctly
accordingtothespecicationsoftheused
bleeder resistor.
5. The motor is in abrupt
acceleration/deceleration
status. The maximum
brakingenergyexceeds
the energy absorption
value.
Conrmtheacceleration/deceleration
time during running and measure the DC
busvoltagebetweenPandCtocheck
whether the voltage exceeds the fault
threshold during deceleration.
Ensure that the input voltage of main
circuitiswithinthespecications.Then
increase the acceleration/deceleration time
within the allowed range.
6. The bus voltage
sampling value has a
large deviation from the
actually measured value.
Checkwhether200B-1Bh(busvoltage)
iswithinthefollowingspecications:
220Vdrive:200B-1Bh>420V
Measure the DC bus voltage between
PandCandcheckwhethertheDC
bus voltage is normal and smaller than
200B-1 Bh.
Contact Inovance for technical support.
7. The servo drive is faulty.
The fault persists after the main circuit is
powered off and on several times.
Replace the servo drive.
■ E3.410: Main circuit undervoltage
Cause:
The DC bus voltage between P and N is lower than the overvoltage threshold.
220Vdrive:Normalvalue:310V,overvoltagethreshold:200V.
Probable Cause ConrmingMethod Corrective Action
1. The power supply of
main circuit is unstable or
power failure occurs.
Measure whether the input voltage of
the main circuit (RST) on non-drive side
and drive side is within the following
specications:
220Vdrive:
Effectivevalue:220V–240V
Allowederror:–10%to+10%(198Vto
264 V)
The voltages of all three phases need to
be measured.
Improve the power capacity.
2. Instantaneous power
failure occurs.
3. The power voltage drops
during running.
Checkthepowerinputvoltageand
checkwhethermainpowerisapplied
tootherdevices,resultingininsufcient
power capacity and a voltage dip.
